1. 可直接焊锡。
2. 可用自动绕线机高速绕线。
3. 满足欧盟ROHS2.0,HF无卤，REACH SVHC环保要求。
产品构造图
| 导体/conductor | 裸铜线、漆包线、镀锡线、绞线 Bare copper wire, enameled wire, tinned wire, strand，Litz wire |
| 材质/Texture of material | PET、ETFE、TAPE |
| 耐温等级/Temperature tolerance grade | Class B ,Class F |
| 耐压/Withstand voltage | AC 6000V/60S 无击穿/No breakdown |
| 层级/Hierarchy | 四层/four layers |
| 应用范围/Application scope | 小型变压器、手机充电器、快充无线充电器、汽车电子Small transformer, mobile phone charger fast charging Wireless charger, automotive electronics |
| 通过安规/Pass safety regulations | UL2353 , UL60950 , UL1446 |
| 序号 | 导体 | 成品 | 最大导体电阻 (at 20℃Ω/KM) |
最小伸长率(%) | ||
| 直径(mm) | 公差(mm) | 目标外径(mm) | 公差(mm) | |||
| 1 | 0.20 | ±0.008 | 0.47 | ±0.020 | 607.6 | 15 |
| 2 | 0.25 | ±0.008 | 0.52 | ±0.020 | 382.5 | 15 |
| 3 | 0.26 | ±0.010 | 0.53 | ±0.020 | 358.4 | 15 |
| 4 | 0.28 | ±0.010 | 0.55 | ±0.020 | 307.3 | 15 |
| 5 | 0.30 | ±0.010 | 0.57 | ±0.020 | 262.9 | 20 |
| 6 | 0.32 | ±0.010 | 0.59 | ±0.020 | 230.0 | 20 |
| 7 | 0.35 | ±0.010 | 0.62 | ±0.020 | 191.2 | 20 |
| 8 | 0.40 | ±0.010 | 0.67 | ±0.020 | 145.3 | 20 |
| 11 | 0.45 | ±0.010 | 0.72 | ±0.020 | 114.2 | 20 |
| 12 | 0.50 | ±0.010 | 0.77 | ±0.020 | 91.4 | 20 |
| 13 | 0.55 | ±0.020 | 0.82 | ±0.020 | 78.2 | 20 |
| 14 | 0.60 | ±0.020 | 0.87 | ±0.020 | 65.3 | 20 |
| 15 | 0.65 | ±0.020 | 0.92 | ±0.020 | 55.3 | 20 |
| 16 | 0.70 | ±0.020 | 0.97 | ±0.020 | 47.5 | 20 |
| 17 | 0.75 | ±0.020 | 1.02 | ±0.020 | 41.2 | 20 |
| 18 | 0.80 | ±0.020 | 1.07 | ±0.020 | 36.1 | 25 |
| 19 | 0.85 | ±0.020 | 1.12 | ±0.020 | 31.9 | 25 |
| 20 | 0.90 | ±0.020 | 1.17 | ±0.020 | 28.4 | 25 |
| 21 | 0.95 | ±0.020 | 1.22 | ±0.020 | 25.4 | 25 |
| 22 | 1.00 | ±0.030 | 1.27 | ±0.020 | 23.3 | 25 |
主要用于高频变压器、电源、电感、充电器、适配器、通信网络、LED导线等。
