Compatibility Range
Compatible with magnetic cores with outer diameters of 14-45mm, specifically for common mode products, butterfly products, and three-winding products (differential mode not supported).
Machine dimensions: Length 80CM x Width 36CM x Height 88CM
Functional Features
Special fixture clamps both sides of the magnetic core for precise positioning, solving the difficulty of inserting separators into common mode products.
This machine is an electric intelligent supplementary model, ideal for: common mode products with housings on both sides (top and bottom), as well as products with narrow inner walls that make it difficult to leave space for separators.
Exclusive Functional Highlights
1. Precise turn counting: Based on automatic turn counting, adds a precise turn counting function—missed hooks are not counted, eliminating the need for workers to count turns manually, saving effort and improving efficiency.
2. Automatic rewinding: Through system-set layering angles, automatic rewinding is achieved with 360-degree rotation—no need to flip the magnetic core, saving manual flipping time and increasing efficiency by 30%.
3. Adjustable hook needle speed and stroke: Compared to manual operation, it ensures copper wire sits tightly against the core wall while also saving material, improving efficiency and reducing effort.
4. Safety light curtain: Multiple safety protections including protective panels, customized safety light curtains, and software protection programs ensure operator safety.
Fully electric—just plug in and use, no air supply required.
