Détails du produit
| Type | Dimensions (mm) | |||||
| A | B | C | D | E | F | |
| P19/9 | 19+0/-0.5 | 13.3±0.3 | 2.0±0.2 | 4.5±0.15 | 2.5±0.15 | |
| P22/13 | 21.6±0.4 | 18.2±0.4 | 9.25±0.2 | 4.55±0.2 | 6.7±0.2 | 4.7±0.2 |
| P25/16 | 24.5±0.5 | 20.8±0.5 | 11.3±0.3 | 5.9±0.3 | 8.1±0.25 | 5.9±0.25 |
| Type | Paramètres | AL (nH/N²) ±25% | Poids (g) | ||||
| C1 (mm⁻¹) | Le (mm) | Ae (mm²) | Ve (mm³) | RP2K3 | RP2K4 | ||
| P19/9 | 7.10 | 22.3 | 3.14 | 1819 | 700 | 850 | 14.3 |
| P22/13 | 0.49 | 31.5 | 63.0 | 2019 | 400 | ||
| P25/16 | 0.43 | 38.32 | 89.1 | 3413 | 4800 | 5100 | 18.1 |
