Détails du produit
| Modèle | Dimensions (mm) | ||||||
| A | B | C | D | F | H | J | |
| SQ36/45 | 45.0±0.5 | 36.0±0.4 | 13.0±0.3 | 11.0±0.3 | 28.0±0.3 | 8.5±0.2 | 12.5±0.2 |
| SQ36/33 | 33.0±0.5 | 36.0±0.4 | 12.0±0.3 | 13.0±0.3 | 16.0±0.3 | 8.5±0.2 | 11.5±0.2 |
| SQ31/29 | 28.8±0.4 | 31.0±0.4 | 11.1±0.3 | 10.0±0.4 | 16.8±0.4 | ||
| SQ28/26 | 28.0±0.4 | 26.0±0.4 | 9.5±0.3 | 10.0±0.4 | 19.0±0.4 | ||
| SQ27/25 | 27.1±0.5 | 24.6±0.4 | 9.5±0.3 | 9.2±0.3 | 17.9±0.3 | 4.6±0.3 | 7.7±0.3 |
| Modèle | Paramètres | AL (nH/N2)±25% | Poids (g) | ||||
| C1 (mm-1) | Le (mm) | Ae (mm2) | Ve (mm3) | RH7K | RH10K | ||
| SQ36/45 | 0.785 | 108.3 | 137.9 | 14947 | 11000 | 15500 | 73.0 |
| SQ36/33 | 0.749 | 88.1 | 117.6 | 10369 | 11000 | 15500 | 51.0 |
| SQ31/29 | 0.749 | 88.1 | 117.6 | 10369 | 10000 | 1400 | 34.0 |
| SQ28/26 | 1.04 | 69.3 | 66.9 | 4637 | 5000 | 8000 | 22.0 |
| SQ27/25 | 1.24 | 70.01 | 65.4 | 3955 | 7600 | 10000 | 21.0 |
