Détails du produit
| Modèle | Dimensions (mm) | ||||
| A | B | C | Emin | F | |
| UU6 | 6.0±0.25 | 15.0±0.2 | 8.5±0.2 | 2.0 | 13.0±0.2 |
| UU6.7 | 6.7±0.2 | 11.5±0.5 | 4.0±0.2 | 2.7 | 9.5±0.5 |
| UF9.8 | 9.8±0.2 | 7.1±0.25 | 4.25±0.2 | 2.6 | 4.3±0.2 |
| UF10.5A | 10.5±0.3 | 11.6±0.3 | 10.0±0.3 | 5.35 | 9.1±0.3 |
| UF10.5B | 11.0±0.4 | 8.3±0.25 | 5.3±0.2 | 5.3 | 5.8±0.2 |
| UF16 | 16.2±0.3 | 10.6±0.3 | 6.6±0.2 | 6.2 | 7.0±0.2 |
| UF32.5 | 32.5±0.7 | 27.6±0.3 | 12.5±0.3 | 13.0 | 18.0±0.3 |
| UU45 | 45.0±0.8 | 21.2±0.3 | 11.95±0.3 | 30.5 | 14.15±0.3 |
| UF70 | 70.0±1.2 | 60.0±0.3 | 41.0±0.4 | 58.0 | 32.0±1.0 |
| UF16/32 | 60.5±1.5 | 32.0±0.5 | 15.8±0.5 | 29.0 | 20.0±0.5 |
| Modèle | Paramètres | AL (Nh/N2) ±25% | Poids (g) | |||
| C1 (mm-1) | Le (mm) | Ae (mm2) | Ve (mm3) | RH10K | ||
| UU6 | 3.85 | 62.5 | 16.2 | 1020 | 610(RP2K3) | 5.4 |
| U6.7 | 6.79 | 51.6 | 7.6 | 404 | 1470 | 2.2 |
| UF9.8 | 4.46 | 34.10 | 7.70 | 261 | 1660 | 1.5 |
| UF10.5A | 2.25 | 55.37 | 24.6 | 1363.8 | 1200(RP2K3) | 7.2 |
| UF10.5B | 1.50 | 40.80 | 27.5 | 1128.6 | 1700 | 3.2 |
| UF16 | 1.95 | 53.7 | 27.6 | 1480 | 3070 | 7.2 |
| UF32.5 | 1.10 | 130.0 | 118.0 | 15400 | 2000(RP2K3) | 76.0 |
| UF45(UU45) | 1.68 | 141.0 | 83.7 | 11800 | 4200(RH10K) | 60.0 |
| UF70 | 1.47 | 250.0 | 170.0 | 42500 | 8800 | 1555 |
| UF16/32 | 1.097 | 182 | 168 | 30845 | 2350(RP2K4) | 158 |
